Plastic Granulator Machine

Plastic granulator machine, also known as a plastic crusher or plastic recycling machine, is a device specially used to crush and process various waste plastics, such as plastic bottles, films, pipes, plates, and injection molded parts, into uniform-sized plastic particles through mechanical shearing, tearing, and impact. These recycled plastic particles can be re-invested in the production process of plastic products as recycled raw materials, thereby realizing the recycling of plastics, reducing environmental pollution, and reducing production costs. Plastic granulator is an indispensable key equipment in the plastic recycling industry and plastic product manufacturers. Have you decided to invest in YG’s high-quality granulator for your project? Contact us now.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800

Get a Free Quote

Plastic Granulator Machine Parameter:

Model YG-TS35 YG-TS45 YG-TS55
Tube size range 1~4mm 2~8mm 8~15mm
Screw size 35mm 45mm 55mm
Screw L/D 28:1 28:1 28:1
Voltage 380V 380V 380V
Power 5.5Kw 11Kw 15kW
Production capacity 8~10Kg/h 15~18Kg/h 30~35Kg/h

Get a Free Quote

Working Principle of Plastic Granulator:

YG high-efficiency plastic crusher mainly crushes the plastic materials entering the crushing chamber through the shearing action between the high-speed rotating knife disc and the fixed knife. The materials enter the crushing chamber from the feed hopper and are initially crushed by the impact and shearing of the high-speed rotating knife disc. Then, the crushed materials continue to be ground and squeezed by the knife in the crushing chamber until their size is smaller than the mesh aperture, and finally, they are discharged from the discharge port through the mesh to form uniform plastic particles.

Functional Features of the Granulator:

  1. Efficient crushing capacity: With optimized tool design and powerful power system, it can quickly and effectively crush various types of plastics, including films, bottles, pipes, plates, etc.
  2. Adjustable particle size: By replacing screens of different specifications, the size of the final plastic particles can be flexibly adjusted to meet the needs of different applications.
  3. Safe and reliable operation: Equipped with multiple safety protection devices, such as overload protection, emergency stop buttons, etc., to ensure the safety and stability of the equipment during operation.
  4. Simple and convenient maintenance: The structural design is reasonable, easy to disassemble and clean, and daily maintenance work is simple and convenient, reducing maintenance costs.
  5. Low-noise operation: The sound insulation design and shock absorption measures are adopted to effectively reduce the noise generated by the equipment during operation and improve the working environment.
  6. Wide applicability: It is suitable for various plastic recycling and reuse scenarios and is an ideal choice for the plastic processing industry.

Get a Free Quote

Plastic Granulators Are Mainly Used in the Following Areas:

  1. Plastic recycling: crushing discarded plastic bottles, films, pipes, plates, etc. into small particles, which are convenient for subsequent cleaning, melting, and reprocessing to make new plastic products. This is the main application area.
  2. Plastic product production: In some plastic product factories, it is used to process scraps and waste generated during the production process, crush them, and put them back into production as recycled materials, reducing waste and reducing costs.
  3. Waste treatment: In garbage treatment plants, plastic granulators can perform preliminary crushing of plastics in mixed garbage, which is convenient for subsequent classification and treatment.

Why Choose YG High-Efficiency Plastic Pulverizer?

  1. Improve production efficiency: The efficient crushing capacity can quickly process a large amount of waste plastics, significantly improve production efficiency, and shorten production cycles.
  2. Reduce operating costs: Wear-resistant knives and stable performance reduce equipment failure rate and maintenance costs while reducing energy consumption.
  3. Improve product quality: The uniform particle size provides high-quality raw materials for subsequent plastic processing, which helps to improve the quality of the final product.
  4. Help environmental protection: Converting waste plastics into reusable resources contributes to environmental protection and sustainable development.

For companies that are looking for plastic granulators for sale, YG’s high-efficiency plastic pulverizer is undoubtedly a cost-effective choice.

Get a Free Quote

Plastic Granulator Machine for Sale – YG Machinery

In summary, as a high-performance industrial-grade plastic granulator, YG high-efficiency plastic crusher is undoubtedly your ideal choice in the field of plastic recycling and waste treatment with its excellent crushing efficiency, stable operating performance, wide applicability, and significant economic and environmental benefits for users. If you are looking for a plastic granulator machine that can significantly improve production efficiency, reduce operating costs, and contribute to sustainable development, please contact us immediately for professional consultation and customized solutions.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
