In the golden season at the end of 2024, a well-known geological exploration company in Cambodia decided to introduce a batch of high-performance hydraulic drilling equipment to accelerate the advancement of its multiple key infrastructure projects in the country. Among many options, our company was fortunate to provide them with a customized full hydraulic core drilling rig solution. The following is a detailed introduction to this customer case, hoping to provide a reference for other customers.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
Fully Hydraulic Core Drilling Rig Parameter:
| Model | YGX-400 | YGX-600 | YGX-800 | YGX-1000 |
| Drilling Depth(M) | 180-400-500 | 200-600-650 | 400-800-1000 | 500-1000-1100 |
| Rated pressure(MPA) | 21 | 21 | 25 | 28 |
| Rated Flow(L/min) | 168 | 192 | 260 | 300 |
| Heat Dissipation Mode | Air cooling+water cooling | |||
| Engine Brand | Yuchai | Yuchai | Yuchai | Cummins |
| Rated power/speed | 78kW/ 2400r/min | 92kW/ 2400r/min | 92kW/ 2400r/min | 154kW/
2400r/min |
| Drilling Angle(°) | 0-90 | 45-90 | 45-90 | 45-90 |
| Lifting Force(T) | 12 | 16 | 24 | 30 |
| Feed Force(T) | 6 | 8 | 12 | 15 |
| Hydraulic Mud pump flow | 30-90（L/min） | 30-90（L/min） | 90-180（L/min） | 90-180（L/min） |
| Hydraulic Mud pump power | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) |
| Dimension | 4000*1900*1800mm | 4000*2000*1800mm | 5500*2100*2000mm | 6000*2200*2400mm |
| Weight | 4.3T | 4.5/5.5T | 6.5T | 7.5T |
Project Background and Customer Needs
Our client is a geological exploration company that has been deeply rooted in Cambodia for many years, mainly engaged in mineral exploration, geological surveys, and engineering surveys. With the continuous expansion of the company’s business, they are in urgent need of a batch of core drills with excellent performance to improve exploration efficiency and accuracy.
The client’s projects are mainly concentrated on the following aspects:
- Mineral exploration: Exploration of potential mineral deposits, such as gold, copper, iron, etc.
- Geological survey: Investigate the stratigraphic structure, geological structure, and geological history.
- Engineering survey: Exploration of foundation, rock, and soil body groundwater, etc.
Based on the above project requirements, the customer put forward the following requirements for the core drill:
- Efficiency: Fast drilling speed and high coring rate to shorten the exploration cycle.
- Strong adaptability: Able to adapt to various complex geological conditions, including hard rock, soft rock, broken rock formations, etc.
- Stability: Smooth operation and low failure rate to ensure the smooth progress of exploration work.
- Safety: Equipped with complete safety devices to ensure the life safety of operators.
Fully Hydraulic Core Drilling Rig Project In-Depth Communication and Solution Development
After initially understanding the customer’s needs, our sales team immediately communicated with the customer in-depth, asked the customer about the project situation, geological conditions, budget range, etc. in detail, and recommended several suitable core drilling rig models according to the customer’s needs, and customized a full range of solutions including full hydraulic core drilling rigs for the customer.
- Full hydraulic core drilling rig: Select a full hydraulic core drilling rig with high torque, high speed, and high feed force to meet the customer’s drilling needs under various geological conditions.
- Drilling system: Provide a series of high-quality drill rods, drill bits, and core tubes to ensure the coring rate and drilling efficiency.
- Auxiliary equipment: Equipped with auxiliary equipment such as mud pumps and drill rod pullers to improve the overall performance of the drilling rig.
- Operation training: To ensure that the customer team can get started quickly, we provide comprehensive operation training courses, from basic operations to advanced maintenance skills, to ensure that every operator can master them proficiently.
- After-sales service commitment: We promise to provide customers with 24-hour online technical support, as well as regular equipment inspection and maintenance services to ensure that the equipment is always in the best working condition.
Fully Hydraulic Core Drilling Rig Equipment Delivery and Customer Feedback
After the solution was determined, we immediately arranged production and delivered the equipment to the customer on time. Our technical team also provided professional training and guidance to customers to ensure that customers could operate and maintain the equipment proficiently.
After a period of use, customers gave high praise to our fully hydraulic core drill:
- “This drill has excellent performance, fast drilling speed, and high coring rate, which greatly improves our exploration efficiency.”
- “The drilling rig has good stability and can operate stably even under complex geological conditions, and rarely fails.”
- “Your after-sales service is very thoughtful, and problems can be solved in time, which makes us feel at ease. We feel deeply at ease to cooperate with you, and we will continue to trust and recommend your products in the future.”
The customer also said that our fully hydraulic core drill has brought them significant economic and social benefits. They not only shortened the exploration cycle, and reduced costs, but also improved the exploration accuracy. This successful cooperation not only demonstrated our leading position in the field of hydraulic drilling equipment but also injected strong impetus into Cambodia’s infrastructure construction. We firmly believe that the fully hydraulic core drilling rig will continue to shine in various construction projects in Cambodia and around the world, helping more customers realize their construction dreams. If you also need water well drilling equipment, please contact us.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
