Extruded Curb Machine
An extruded curb machine, also known as a slip-form paver, is a special equipment used for the continuous pouring of concrete curbstones, drainage ditches, and other small concrete components on site. The concrete curb and gutter machine plays an important role in the construction of modern roads, municipal administration, landscape, and other projects with its advantages of high efficiency, economy, and reliable quality. At present, we have sold to New Zealand, Cambodia, Malaysia, Iraq, Thailand, Australia, South Africa, and other countries, and customers have very good feedback. Of course, if your project also needs an extruded curb machine, why not choose YG and contact us now?【WhatsApp/WeChat/Skype/Phone】+86 136 1385 6800
Extruded Curb Machine Parameter:
Model
YG-20
YG-30
Type
Portable wheel type
Crawler portable
Steering system
Automatic steering system
Automatic steering system
Engine
65kw, AC380V four-cylinder turbo diesel engine
65kw
Rated speed
1500rpm
Curb size
Height≤600mm，width≤2000mm
Height≤1100mm，width≤2000mm
Forming method
high-frequency vibrator Attached vibration motor
Minimum turning radius
6800mm
6800mm
Paving speed
1—7m/min adjustable
1—10m/min
Hopper volume
1m³
1m³
Machine size
5000*2400*2800mm
5200*2400*2800mm
Weight
6000kg
7000kg
Extruded Curb Machine Widely Used: Serving Various Types of Engineering Construction
Construction of curbstones for urban roads and highways.
Central isolation belts and side ditches of highways.
Edge separation of parking lots, industrial parks, residential areas, and other areas.
Edge shaping of places such as garden landscapes, sidewalks, and bicycle lanes.
Water conservancy projects such as drainage ditches and canals.
The curbstone slip form machine can also be used to make various special-shaped concrete components according to different molds and configurations, such as:
Special-shaped curbstones: Meet special landscape design or functional requirements.
Curbstones with drainage holes: Improve drainage efficiency.
Curbstones with cable troughs: Facilitate the laying of underground pipelines.
3 Cases and Feedback of Using the Kerb Slipform Machine:
Case 1: Fast construction of highways
New Zealand customers purchased it for highway expansion projects. The construction period was tight and the construction of curbstones and central isolation belts needed to be completed quickly. After the extrusion-type curbstone machine was adopted, the construction speed was greatly improved. The original construction period of several weeks was shortened to several days, which effectively alleviated the traffic pressure and completed the project delivery ahead of schedule. Customer feedback: The machine is not only fast, but also the quality of the formed curbstones is very good, with a smooth surface and smooth lines.
Case 2: Improve the quality of urban road reconstruction
Malaysian customers purchased it to replace the damaged curbstones and improve the overall aesthetics of the road to renovate the old roads. After the extrusion type curbstone machine was adopted, not only the construction speed was fast, but also the shape and size of the curbstones could be flexibly adjusted according to the actual situation of the road, which better met the design requirements. The renovated road has a new look and has been well-received by the citizens. Customer feedback: The machine is easy to operate and maintain, which greatly reduces the difficulty and cost of construction.
Case 3: Finely crafted landscape engineering
The landscape engineering of a large park in Cambodia requires the construction of winding garden paths and flower bed edges. With the extrusion-type curbstone machine, you can easily cope with various curved shapes and create beautiful and natural landscape effects. The formed curbstone has smooth lines, which complement the surrounding green environment and improve the overall quality of the park. Customer feedback: The machine is highly adaptable and can meet various complex modeling requirements, providing greater freedom for landscape design.
Extruded Curb Machine for Sale in YG Machinery
Extruded curbstone machines have become indispensable and important equipment in modern road and municipal engineering construction with their advantages of high efficiency, economy, and reliable quality. With the continuous advancement of technology, concrete curb machines will play a more important role in future infrastructure construction. If you are looking for an efficient curbstone construction solution, extruded curbstone machines are undoubtedly an ideal choice worth considering. If you need more specific information, such as machine parameters and prices for a specific model, please contact us now.【WhatsApp/WeChat/Skype/Phone】+86 136 1385 6800
