YG’s expandable container house has a simple and elegant appearance, and the main body is transformed from a container. It has two standard specifications: 20ft expandable container homes for sale and 40ft expandable container homes for sale. The box’s exterior is made of high-strength corrosion-resistant steel, which is sturdy and durable and can withstand various bad weather. The expandable structure uses special slide rails and splicing technology, and with the help of hydraulic or manual devices, it is easy to expand the space. If you want to know more about portable container houses, contact us now.【WhatsApp/WeChat/Skype/Phone】+86 136 1385 6800
Expandable Container Homes Parameter:
20FT Basic Characteristics
|
External dimension (mm) | W6320*L5900*H2480(Side 2270) |
Internal dimension (mm) | W6160*L5560*H2240(Side 2150) | |
Folded state (mm) | W2200*L5900*H2480 | |
Total mass (kg) | 2500 | |
30FT Basic Characteristics
|
External dimension (mm) | W6360*L9000*H2480(Side 2180) |
Internal dimension (mm) | W6200*L8660*H2240(Side 2060) | |
Folded state (mm) | W2200*L9000*H2480 | |
Total mass (kg) | 3750 | |
40FT Basic Characteristics
|
External dimension (mm) | W6240*L11800*H2480(Side2180) |
Internal dimension (mm) | W6080*L11540*H2200(Side2060) | |
Folded state (mm) | W2200*L11800*H2480 | |
Total mass (kg) | 4400 | |
Smaller Fold Size
|
External dimension (mm) | W4820*L5900*H2480(Side2270) |
Internal dimension (mm) | W4660*L5560*H2240(Side2150) | |
Folded state (mm) | W700*L5900*H2480 | |
Total mass (kg) | 1850 |
Comparison Between Folding Houses and Other Traditional Houses and Other Mobile Houses:
Compared with traditional houses
- Construction cycle: Traditional houses usually take months or even years from laying the foundation to overall completion, involving complex construction processes and collaboration with multiple types of work. Folding houses adopt modular design, are prefabricated in the factory, and after being transported to the site, a few people can complete the construction in just a few hours, greatly shortening the waiting time for moving in or use.
- Cost: Traditional house construction costs are high, not only building materials and labor costs but also a series of costs such as land acquisition. Folding houses are standardized in production, with relatively low material costs, and no large-scale construction team is required, which greatly reduces the installation cost and makes the overall cost much lower than traditional houses. In addition, the cost of folding houses is relatively low when transporting and moving.
- Mobility: Once a traditional house is built, its location is fixed and difficult to move. Folding houses are light and flexible and can be easily transported to different locations according to needs, meeting the user’s flexible change of living location, such as moving from a campsite to a commercial activity venue.
- Personalized customization: Although traditional houses can also achieve personalized design, the customization cost is high due to the complexity of construction. The modular design of the folding house enables it to be easily customized. From the exterior painting to the internal layout, it can be built according to the user’s preferences to meet diverse needs.
Compared with other mobile houses
- Space utilization: RVs are limited by the body structure, the internal space is relatively narrow, and the expansion is limited. Although the container house has a large space, it generally needs to be renovated on-site, and the space layout is relatively fixed. After the folding house is unfolded, the space is spacious and the layout is flexible. It can provide a larger use space under a limited floor area to meet the space requirements of different scenarios.
- Convenience of construction: The transformation of container houses usually requires professional tools and personnel, and the construction process is relatively complicated. The folding mechanism of the folding house is cleverly designed. It only needs a simple operation to quickly complete the unfolding and folding. No professional technical knowledge is required, which reduces the threshold for use.
- Energy consumption and comfort: The folding house uses thermal insulation sandwich panels and energy-saving doors and windows, which can effectively insulate and heat, reduce the use of air conditioning and heating, and reduce energy consumption. In contrast, some mobile houses have poor thermal insulation performance and it is difficult to provide users with a comfortable and stable living environment in different seasons.
- Appearance design: Compared with the relatively single appearance of some RVs and container houses, the appearance of folding houses keeps up with fashion trends, has diverse styles, is more visually appealing, can better integrate into different scenes, and attracts consumers’ attention.
The Following Simple Steps Are Usually Followed for the Quick Installation of a Folding House:
- Site preparation: First, flat and solid ground is required to ensure the stability and safety of the house placement.
- Unfolding and positioning: Transport the folding house to the predetermined location, and the house can be quickly unfolded and formed by simple manual or mechanical operations (for example, loosening the lock, pulling the handle, or operating the electric button).
- Fixed connection: After unfolding, check and fix the various connecting parts of the house to ensure the stability of the structure. Some models may require simple bolt connection or snap fixation.
- Water and electricity access: Connect the reserved water and electricity interfaces, usually using standardized quick-plug interfaces, which are convenient and fast. If necessary, simple internal line connections can be made according to the instructions.
- Interior arrangement: After a simple internal layout and arrangement, it can be put into use.
The installation is very simple, usually without complex tools and professional skills. Our expandable container homes for sale in the worldwide design fully consider the convenience of users and provide clear and easy-to-understand installation manuals and video guidance.
At the same time, we provide a professional after-sales service team. If you encounter any problems during the installation process, you can contact us at any time, and we will provide timely technical support and guidance.
