In modern construction projects, ground flatness is one of the important indicators for measuring project quality. Whether an industrial plant, commercial, or residential building, a flat ground is the basis for efficient operation, safe use, and beauty and comfort. Traditional ground leveling methods, such as manual scraping or mechanical vibration, are inefficient, poor in precision, and labor-intensive, making it difficult to meet the growing demand for high-standard ground. The concrete laser leveling machine realizes the automation, intelligence, and high precision of ground leveling, greatly improving the efficiency and quality of ground construction. It has been successfully sold to the United States and other global markets, winning wide acclaim from customers. If you are interested, contact us now.【WhatsApp/WeChat/Skype/Phone】+86 136 1385 6800
Concrete Laser Leveling Machine Parameter:
| Model | YGJX31 | YGJX32 | YGJX33 | YGJX34 |
| Engine | ||||
| Model | Generator set | GX390 Electric start | GX390 Electric start | GX390 Electric start |
| Power | 2.0kW | 13hp/3600rpm | 13hp/3600rpm | 13hp/3600rpm |
| Fuel tank (L) | 14.5 | 6.5 | 6.5 | 6.5 |
| Running device | ||||
| Drive | Motor | Hydraulic motor | Hydraulic motor | Hydraulic motor |
| Running mode | Infinitely variable speed | Handle control, step-less speed | Handle control, step-less speed | Handle control, step-less speed |
| Running speed(m/min) | 0-36 | 0-45 | 0-65 | 0-45 |
| Suggest working speed(m/min) | 5 | 5 | 5 | 5 |
| Screed head | ||||
| Type | Self-leveling | Electric control, self-leveling | Self-leveling | Hydraulic control, self-leveling |
| Width | 2500mm | 2500mm | 2500mm | 2500mm |
| Exciting force | 500N | 500N | 500N | 500N |
| Vibration frequency | 50Hz | 50Hz | 50Hz | 50Hz |
| Laser control system | ||||
| Control type | Microcomputer laser scan | Microcomputer laser scan | Microcomputer laser scan | Microcomputer control |
| Operation mode | Walk-behind | Walk-behind | Walk-behind | Walk-behind |
| Forward and reverse | Handgrip control, step-less speed-walking | Hydraulic control | Handgrip control, step-less speed-walking | Hydraulic control |
| Size and weight | ||||
| Working size(mm) | 2758*2622*1980 | 2740×2659×1980 | 2578×2643×1980 | 2780*2622*1980 |
| Weight(kg) | 295 | 365 | 380 | 410 |
Concrete Laser Leveling Machine for Sale in the USA:
In a major construction project in the heart of New York City, a large-scale commercial complex was being built. The project required a vast area of perfectly level concrete floors for retail spaces, offices, and parking areas. The construction company initially considered traditional leveling methods but soon realized that they would not be able to meet the strict time and quality requirements.
They decided to invest in a high-quality concrete laser leveling machine from our company. The results were astonishing. The machine was able to level the concrete floors of the entire commercial complex with remarkable precision. The construction time was reduced by 40% compared to what it would have taken with traditional methods. The smooth and level floors not only provided an excellent base for further interior work but also received high praise from the building’s future tenants.
The project manager commented, “The concrete laser leveling machine was a game-changer for our project. It allowed us to complete the concrete work much faster and with a level of precision that exceeded our expectations. The reduction in labor costs was a bonus. We are extremely satisfied with the product and would use it again in future projects.”
Working Principle of Concrete Laser Leveling Machine:
- Laser reference establishment: The laser transmitter emits a rotating laser beam to form an accurate laser reference surface in the construction area.
- Laser scanning and leveling: The laser receiver receives the laser beam signal in real-time, compares the actual ground height with the laser reference height, calculates the deviation value, and transmits the deviation signal to the control system.
- Hydraulic automatic adjustment: The control system automatically controls the hydraulic system to adjust the height of the leveling head according to the deviation signal, so that the scraper always maintains an accurate relative height with the laser reference surface, thereby realizing automatic leveling and precise leveling of the ground.
- Vibration compaction: The hydraulic vibration system drives the vibration plate to vibrate at a high frequency, making the concrete uniformly compacted and further improving the ground quality.
- Travel and operation: The operator controls the travel system to drive the equipment to perform ground leveling operations according to the predetermined route. The equipment automatically completes a series of actions such as leveling, vibration, scraping, etc., to realize automatic and intelligent ground leveling construction.
Advantages of Concrete Laser Leveling Machine:
- Greatly improve construction efficiency: Concrete laser leveling machine has an automated and intelligent operation mode, which is several times more efficient than traditional manual leveling, greatly shortens the construction period, speeds up the project progress, and quickly delivers the project.
- Significantly reduce labor costs: Reduce dependence on labor, significantly reduce labor costs and management expenses, save project budgets, and increase profit margins.
- Create ultra-high flatness ground: Laser precision leveling technology creates high-precision, ultra-flat ground to meet the needs of various high-standard ground projects, and improve project quality and market competitiveness.
- Reduce later maintenance costs: The ground has high density and good flatness, reduces quality problems such as hollowing and cracks on the ground, reduces later maintenance and repair costs, and extends the service life of the ground.
- Improve corporate competitiveness and win more projects: With advanced laser leveling equipment, the company’s construction technology level and project quality will be improved, market competitiveness will be enhanced, more large-scale engineering projects will be won, and business scale will be expanded.
