The skid steer loader is a very practical construction machine. You can think of it as a small but powerful all-purpose construction vehicle. The best part is that it can quickly replace various attachments (like tool heads) to complete a variety of tasks, such as shoveling, carrying, digging, cleaning, crushing, etc. This small, flexible, powerful, multifunctional, and adaptable construction machine is particularly suitable for situations where multiple operations need to be performed on complex surfaces and in small spaces. Do you also need a skid steer loader to complete your project? Contact us now to get a quote.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
Skid Steer Track Loader Parameter:
Item | YG280 | YG380 | YG380C | |||
With Rubber Track | With Chevron Engineering Tyre | With Chevron Engineering Tyre | ||||
Metric | The U.S. | Metric | The U.S. | Metric | The U.S. | |
Max working height(H3) | 2065mm | 81.3inch | 2143mm | 84.37inch | 2143mm | 84.37inch |
Max pin height(H2) | 1803mm | 71inch | 1884mm | 74.17inch | 1884mm | 74.17inch |
Max Dumping height(H1) | 1386mm | 54.6inch | 1488mm | 58.58inch | 1488mm | 58.58inch |
Max Dumping distance(E) | 471mm | 18.5inch | 348mm | 13.7inch | 348mm | 13.7inch |
Max Dumping Angle(a3) | 32° | 32° | 30° | 30° | 30° | 30° |
Rollback of the bucket on the ground(a2) | 33° | 33° | 25° | 25° | 25° | 25° |
Departure angle(a1) | 18° | 18° | 11° | 11° | 16° | 16° |
Total height(H) | 1309mm | 51.5inch | 1233mm | 48.54inch | 1265mm | 50inch |
Ground clearance(F) | 123mm | 4.8inch | 118mm | 4.65inch | 118mm | 4.65inch |
Wheelbase(L1) | 690mm | 27.2inch | 636mm | 25.0inch | 636mm | 25.0inch |
Overall length without bucket(L3) | 1778mm | 70inch | 1752mm | 69.0inch | 1980mm | 78inch |
Total width(W) | 800mm | 31.5inch | 1160mm | 45.67inch | 1160mm | 45.67inch |
Bucket width(B) | 820mm | 32.3inch | 980mm | 38.6inch | 980mm | 38.6inch |
Total length with bucket(L) | 2210mm | 87inch | 2206mm | 86.9inch | 2430mm | 95.7inch |
Turn radius forward turning(R) | 1237mm | 48.7inch | 1307mm | 51.5inch | 1307mm | 51.5inch |
Features of Skid Steer Track Loaders:
- Excellent traction and stability: The track has a larger contact area with the ground, which significantly improves traction and stability on complex terrains such as mud, sand, snow, and slopes. Even on slippery or soft ground, the skid steer track loader can travel steadily and operate efficiently.
- Lower ground pressure: The track disperses the weight of the machine and reduces the ground pressure per unit area. This means that when the skid steer track loader operates on sensitive ground such as lawns, tiles, and asphalt roads, it will cause less damage to the ground and reduce repair costs.
- Stronger propulsion and digging force: The greater traction provided by the track is converted into stronger propulsion and digging force. The skid steer track loader is more efficient and has stronger handling capabilities when performing earthwork, material handling, and other tasks.
- Better climbing and obstacle-crossing capabilities: The structural design of the track makes it easier to overcome obstacles climb slopes, and adapt to more rugged working environments.
- Reliability in bad weather: In rainy, snowy, or muddy environments, wheel skid steer loaders are prone to slipping or sinking, while skid steer track loaders can maintain efficient and reliable working conditions with their excellent traction.
The Application of Skid Steer Loaders in Various Fields:
- Construction: In material handling, it can quickly transfer materials such as sand, gravel, cement, bricks, etc. from the storage area to the construction site to improve transportation efficiency. In foundation construction, the bucket is used for earth excavation and site leveling to lay the foundation for subsequent operations. During demolition operations, installing a breaker can quickly dismantle concrete structures and walls to reduce labor costs.
- Agricultural production and garden maintenance: In agriculture, it can transport feed, fertilizer, and agricultural products. Its flexible steering allows it to move freely on narrow farmland roads and greenhouses. During garden maintenance, lawn mowers, branch crushers, and other devices are installed to trim lawns, clean branches, and keep the garden landscape clean.
- Municipal engineering and sanitation operations: In municipal engineering, it is used for road maintenance, quickly cleans damaged parts of the road surface, and transports construction materials to speed up repairs; when laying pipelines, it transports and installs pipelines to improve construction progress. During sanitation operations, cleaning devices are installed to clean city streets, clean fallen leaves and garbage, and maintain a clean urban environment.
- Industrial warehousing and logistics: In the field of industrial warehousing and logistics, it relies on its strong handling capacity and flexible steering to quickly and accurately move goods in the warehouse, improve the utilization rate of storage space and logistics transportation efficiency, and is widely used in large industrial warehouses and logistics distribution centers.
Skid Steer Track Loader for Sale – YG Machinery
To sum up, the biggest highlight of the skid steer loader is its “multi-function” and “high efficiency”. No matter how complex the construction site environment is or how tedious the task is, it can respond flexibly and efficiently with the advantages of the crawler and a variety of accessories, truly achieving multiple uses of one machine and getting twice the result with half the effort. Choosing a skid steer loader is choosing a reliable tool that can improve efficiency and expand business scope. The strong adaptability given by its crawler chassis and the rich selection of accessories makes it capable of handling a variety of working conditions, helping users stand out in the fiercely competitive market. Contact us for more product information and complete your project efficiently.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
